LINNOU
Creative design with small, thin and deep style. LINNOU lamp's overall minimum size is only Ø 60 * H72mm. LINNOU is named for its compact shape, which saves the hole opening size when installing, effectively solves the problem that the big hole opening on the ceiling may destroy skyline integrity of the space. In addition, the delicate lamps can be lively coordinated with the reflector which has a variety of color. Designers can choose different reflector according to the comprehensive color of ceiling and space, to present both practicability and beauty.
Through the clever and ultra-thin design of adjustable lamps, and the minimum height of lamps is controlled in the range of 75 mm. In satisfying the inside height 80 mm under ceiling, it maximally saves the indoor space. And in view of the small size light's new spring design, under the condition of meet the polarization of 30 degrees, it can effectively solve the problem of installation requirements on thickness 8 ~ 20 mm of ceiling. Design innovation and practicality is presented incisively and vividly in the research and development and application of the LINNOU series downlight.
Product
- Beam Angle：Asymmetric distribution
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , 0-10V , DALI
5W 542LM~7W 829LMLINNOU 60Round Fixed Recessed Vanity Downlight
- Beam Angle：Asymmetric distribution
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , 0-10V , DALI
5W 542LM~15W 1701LMLINNOU 70Round Fixed Recessed Vanity Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.2700K) , 2700K-6000K（e.g.6000K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 55Adjustable Recessed Round Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.2700K) , 2700K-6000K（e.g.6000K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 60Adjustable Recessed Round Tunable White Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 60Round Fixed Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 60Round Adjustable Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 70Round Adjustable Recessed Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Adjustable Recessed Round Pinhole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Fixed Recessed Round Pinhole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , Phase , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Adjustable Recessed Oval Hole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , Phase , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Fixed Recessed Oval Hole Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 70Round Fixed Recessed Downlight
