DIAMOND 100

Recessed Trimless Tunable White Downlight

DIAMOND 100

Lighting Effects

Products Specification:
Type:Recessed Trimless Tunable White Downlight
Cut-Out:ø 100 mm
Beam Angle:25D 35D 45D
Power:15W 20W 25W
CCT:1800K-4000K 2700K-6000K
Weight:0.5KG
Heat-Sink:Aluminum
Surface-Treatment:Painting+Plating
Line Drawing:
General Features:

Accessories :
Reflector Color:
Frame Color:

Select your Model No:

*Please log in before selecting your Model No

Power(W)
  • Power(W)
  • 15W
  • 20W
  • 25W
Beam Angle
  • Beam Angle
  • 25°
  • 35°
  • 45°
CRI
  • CRI
  • Ra>90
Color
  • Color
  • 1800K-4000K(e.g.1800K)
  • 1800K-4000K(e.g.4000K)
  • 2700K-6000K(e.g.2700K)
  • 2700K-6000K(e.g.6000K)
Dimming type
  • Dimming type
  • 4-DALI dimming
Finish
  • Finish
  • White
Reflector
  • Reflector
  • Mirror
IP Rating
  • IP Rating
  • 20-IP20
Accessory
  • Accessory
  • Honeycomb louver
  • Model No

  • Luminaire lumen(LM)

  • Power (W)

  • Beam Angle

  • CRI

  • Color

  • Specification

  • IES

  • DWG

  • manual

  • Favorite

Model No

DR02315-15259018

DR02315-15259040

DR02315-15359018

DR02315-15359040

DR02315-15459018

DR02315-15459040

DR02315-20259018

DR02315-20259040

DR02315-20359018

DR02315-20359040

DR02315-20459018

DR02315-20459040

DR02315-25259018

DR02315-25259040

DR02315-25359018

DR02315-25359040

DR02315-25459018

DR02315-25459040

DR02315-20259027

DR02315-20259060

DR02315-20359027

DR02315-20359060

DR02315-20459027

DR02315-20459060

DR02315-25259027

DR02315-25259060

DR02315-25359027

DR02315-25359060

DR02315-25459027

DR02315-25459060

Luminous Flux (LM)

466LM

814LM

487LM

840LM

477LM

822LM

596LM

1039LM

617LM

1101LM

636LM

1079LM

777LM

1293LM

828LM

1383LM

807LM

1363LM

918LM

1043LM

976LM

1199LM

1025LM

1147LM

1218LM

1333LM

1308LM

1401LM

1253LM

1503LM

Power (W)

15W

15W

15W

15W

15W

15W

20W

20W

20W

20W

20W

20W

25W

25W

25W

25W

25W

25W

20W

20W

20W

20W

20W

20W

25W

25W

25W

25W

25W

25W

Beam Angle

25°

25°

35°

35°

45°

45°

25°

25°

35°

35°

45°

45°

25°

25°

35°

35°

45°

45°

25°

25°

35°

35°

45°

45°

25°

25°

35°

35°

45°

45°

CRI

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Color

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

1800K-4000K(e.g.1800K)

1800K-4000K(e.g.4000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

2700K-6000K(e.g.2700K)

2700K-6000K(e.g.6000K)

Specification
IES
DWG
manual
Favorite
