LINNOU
Creative design with small, thin and deep style. LINNOU lamp's overall minimum size is only Ø 60 * H72mm. LINNOU is named for its compact shape, which saves the hole opening size when installing, effectively solves the problem that the big hole opening on the ceiling may destroy skyline integrity of the space. In addition, the delicate lamps can be lively coordinated with the reflector which has a variety of color. Designers can choose different reflector according to the comprehensive color of ceiling and space, to present both practicability and beauty.
Through the clever and ultra-thin design of adjustable lamps, and the minimum height of lamps is controlled in the range of 75 mm. In satisfying the inside height 80 mm under ceiling, it maximally saves the indoor space. And in view of the small size light's new spring design, under the condition of meet the polarization of 30 degrees, it can effectively solve the problem of installation requirements on thickness 8 ~ 20 mm of ceiling. Design innovation and practicality is presented incisively and vividly in the research and development and application of the LINNOU series downlight.
Product
- Beam Angle：Asymmetrical 17°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non
3W 266LM~3W 287LMLINNOU 253W Fixed Asymmetrical Light- Beam Angle：21° , 31°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 44
- Dimming Type：Non
3W 150LM~3W 244LMLINNOU 253W Fixed Direct Light
- Beam Angle：17° , 30°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non
2W 93LM~2W 228LMLINNOU 35Shelf Light
- Beam Angle：Asymmetrical 17°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non
7W 635LM~7W 760LMLINNOU 407W Fixed Asymmetrical Light- Beam Angle：17° , 30° , 40° , 52°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
7W 456LM~7W 789LMLINNOU 407W Direct Light
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 55Round Adjustable Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 55Round Fixed Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 55Round Adjustable Trimless Recessed Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 55Adjustable Recessed Round Tunable White Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 55Round Fixed Trimless Recessed Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 55Round Fixed Recessed Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.2700K) , 2700K-6000K（e.g.6000K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 55Recessed Trimless Adjustable Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.4000K) , 1800K-4000K（e.g.1800K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 60Round Fixed Recessed Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.4000K) , 1800K-4000K（e.g.1800K) , 2700K-6000K（e.g.2700K) , 2700K-6000K（e.g.6000K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 60Adjustable Recessed Round Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~7W 650LMLINNOU 55Recessed Trimless Tunable White Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 60Round Fixed Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~7W 778LMLINNOU 60Round Adjustable Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 65Round Adjustable Recessed Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 65Round Fixed Recessed Downlight- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI , DMX512
5W 461LM~10W 1137LMLINNOU 65Round Adjustable Trimless Recessed Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 65Round Adjustable Recessed Tunable White Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 65Round Fixed Trimless Recessed Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 65Round Fixed Recessed Tunable White Downlight- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 65Round Fixed Trimless Recessed Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.2700K) , 2700K-6000K（e.g.6000K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 65Round Adjustable Trimless Recessed Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 70Round Fixed Recessed Tunable White Downlight
- Beam Angle：22° , 26° , 30° , 36° , 40° , 54°
- CCT：1800K-4000K（e.g.1800K) , 1800K-4000K（e.g.4000K) , 2700K-6000K（e.g.6000K) , 2700K-6000K（e.g.2700K)
- IP Rating：IP 20 , IP 44
- Dimming Type：0-10V , DALI
5W 192LM~10W 920LMLINNOU 70Round Adjustable Recessed Tunable White Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 70Round Adjustable Recessed Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Adjustable Recessed Round Pinhole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Fixed Recessed Round Pinhole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , Phase , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Adjustable Recessed Oval Hole Downlight
- Beam Angle：15° , 26° , 32° , 48°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20
- Dimming Type：Non , Phase , 0-10V , DALI
5W 417LM~10W 943LMLINNOU 70Round Fixed Recessed Oval Hole Downlight
- Beam Angle：10° , 15° , 26° , 36° , 54°
- CCT：2700K , 3000K , 4000K
- IP Rating：IP 20 , IP 44
- Dimming Type：Non , Phase , 0-10V , DALI
5W 461LM~10W 1137LMLINNOU 70Round Fixed Recessed Downlight
